DCa70USI2 60 hz generaTor • operaTIon anD parTS manUal — rev. #0 (06/28/11) — page 53
generatOr assY.
no. parT no. parT name QTY. remarKS
1 B5110000402 ROTOR ASSY 1
1-1 FIELD ASSY 1
1-2 0601820083 RECTIFIER 3
1-3 0601822664 ZNR 1
1-4 B3120100804 HOLDER, ZNR 1
1-5 B3120100604 INSULATOR WASHER 3
1-6 B3120100604 INSULATOR WASHER 5
1-7 B3111100603 FAN 1
1-8 B2163100004 COUPLING DISK ......................... 3 .....PURCHASE ITEMS 1- THRU 1-9 AS A SET
1-9 0010304016 HEX HEAD BOLT 1
1-9A B2163700004 BALANCING WEIGHT 1
1-9B 0204004000 U-NUT 1
1-10 B3163200104 COUPLING WASHER 2
1-11 0342612030 HEX HEAD CAP SCREW 6
1-12 0046512000 WASHER, FLAT 6
1-13 0071906309 BEARING 1
2 0010310020 HEX HEAD BOLT 8
3 0042510000 WASHER, LOCK 8
4 B5130000303 STATOR ASSY 1
4-1 0845041904 GROMMET 2
5 B3137000803 FIELD ASSY EXCITER 1
6 0016008060 HEX HEAD CAP SCREW 4
7 0042508000 WASHER, LOCK 4
8 B3153000513 END BRACKET 1
9 0017108035 HEX HEAD BOLT 6
10 B3153400504 PACKING 1
11 B3153400404 COVER, BEARING 1
12 0017106016 HEX HEAD BOLT 3
13 0010310025 HEX HEAD BOLT 12
14 0042510000 WASHER, LOCK 12
15 B5131300004 COVER, END BRACKET 1
16 0340406040 HEX HEAD BOLT 1
17 0600815000 NUT 1
18 0041206000 WASHER, FLAT 1
19 B3131300804 COVER, END BRACKET 1
20 0029205012 MACHINE SCREW 4
21 0041205000 WASHER, FLAT 4
22 0605000413 RUBBER SUSPENSION 2
23 0030012000 HEX NUT 2
23A 0040012000 WASHER, LOCK 2
23B 0041212000 WASHER, FLAT 2
