DCa45ssk/ku3 60 hz generaTor • operaTion anD parTs manual — rev. #0 (12/15/11) — page 59
engine and radiatOr assy. (cOntinued)
no. parT no. parT name QTY. remarks
41 011008020 HEX. HEAD BOLT 1
42 Y0199101000 HOSE 1
43 0193601300 HOSE 1
44 0605515170 HOSE BAND 2
45 M1310200904 BRACKET, RADIATOR 1
46 M1310201004 BRACKET, RADIATOR 1
47 M1310201104 BRACKET, RADIATOR 2
48 011008020 HEX. HEAD BOLT 8
49 M9312200104 MOUNT RUBBER 4
50 1502025103C DRAIN JOINT ..............................................1 ................REPLACES P/N M9200000003
51 011008020 HEX. HEAD BOLT 2
52 0802011104 DRAIN BOLT ...............................................1 ................REPLACES P/N M9200200004
53 0150000018 O-RING 1
54 Y0379501000 DRAIN HOSE 1
55 0605515198 HOSE BAND 2
56 0193601000 DRAIN HOSE 1
57 Y0602220910 CLAMP 2
58 011008020 HEX. HEAD BOLT 1
59 0601850239 GROMMET 1
60 M1303200604 ENGINE FOOT 1
61 M1303200704 ENGINE FOOT 1
62 Y0013512025 HEX. HEAD BOLT 8
63 0040012000 WASHER, LOCK 8
64 031112230 PLAIN HASHER 8
65 M1357301004 HARNESS CLAMP 1
66 M1357300804 HARNESS CLAMP 1
67 Y0013512025 HEX. HEAD BOLT 3
68 0040012000 WASHER, LOCK 3
69 031112230 WASHER, FLAT 3
70 M1357300904 HARNESS CLAMP 1
71 0010510020 HEX. HEAD BOLT 2
72 0040010000 WASHER, LOCK 2
73 031110160 WASHER, FLAT 2
74 1J41905810 KIT, ELEMENT 1
75 1584139010 SWITCH, OIL PRESSURE 1
76 5160137670 SWITCH, THERMOMETER 1
77 T106365660 SENSOR, WATER TEMP 1
78 3824032830 SWITCH, THERMOMETER 1
79 5671342930 ELECT/MAG/TIC. PICKUP 1
