6.12. [sysconf]
This command displays system information and configurations.
usr/config$ sysconf
System information and configuration
Usage:
sysconf [-print] [-idtime digit] [-bf digit] [-keypad dtmf]
[-faxtype type][-2833type type][-lcdrop ON/OFF]
[-droptime digit][-eod digit] [-callerid type]
[-service used][-dtmfstart digits] [-dtmfend digits]
sysconf -print
-print Display system overall information and configuration.
-idtime Inter-Digits time.(1~10 sec)
-service Specify gateway service type. (0: Dial in service,
1: HotLine service.)
-keypad Select DTMF type: 0=In-band,
1=RFC2833.
-faxtype FAX Payload Type (range:96~128 inter-used:100,102~105)
-2833type RFC2833 Payload Type (range:96~128 inter-used:100,102~105)
-lcdrop Disconnect Supervision(Loop Current Drop) (ON:1 / OFF:0)
-droptime Period of Loop Current Drop (ms)
-eod End of Dial Digit setting(0: none, 1: *, 2: #)
-callerid Caller ID Type setting, 0: Disable,
1: FSK(BELLCORE),
2: DTMF,
3: NTT.
-dtmfstart DTMF CallerID Start Symbol.
-dtmfend DTMF CallerID End Symbol.
Example:
sysconf -keypad 0 -eod 2 -callerid 1
Parameter Usage:
-print
Show the sysconf current status.
-idtime
Set the duration (in second) of two pressed digits in dial mode as
timed out. If after the duration user hasn’t pressed next number, it
will dial out all number pressed (1-10 seconds).
-service
Specify gateway service type. (0: Dial in service, 1: HotLine
service.)
-keypad
DTMF replay type. When value is “1”, FXS Gateway will transfer
DTMF signal via RTP payload as defined in RFC2833. When the
value is set to “0”, the DTMF type is set as In-band.
-faxtype
FAX Payload Type. Rrange:96~128 inter-used:100,102~105.
-2833type
RFC2833 Payload Type. Range: 96~128 inter-used: 100,
102~105.
-lcdrop
Disconnect Supervision (Loop Current Drop) (ON:1 / OFF:0).
