28
A PPLICATIONS AND P ROTOCOLS
The model number on each scanner includes the scanner number and factory
default communications protocol.
Scanner
Version
Identifier
Communication Protocol(s)
-9 OCIA* and RS232 Transmit/Receive
-00 Laser Emulation* and RS232 Transmit/Receive*
-11 IBM 468X/469X, RS232-TXD, RXD, RTS, CTS
-14 RS232-TXD, RXD, RTS, CTS, DTR, DSR
-38
Low Speed,
Serial Emulation or Keyboard Emulation Mode
-40 Full Speed USB
-41 RS232/Light Pen Emulation*
MS9524
and
MS9544
-47
Keyboard Wedge, Stand-Alone Keyboard and
RS232 Transmit/Receive
* PDF bar codes are transmitted as Code 39 for these interfaces. Acceptance
on host side is dependent on the host's ability to handle large amounts of data.
The MS9524/44 Series Hand-Held Laser Scanner with built-in PC Keyboard
Wedge Interface is designed for Keyboard emulation use only. Many RS232
configurable functions available in other Metrologic scanners are also available
as keyboard wedge functions.
The following are the most important selectable options specific to the keyboard
wedge:
Keyboard Type
• **AT (includes IBM® PS2 models 50, 55, 60, 80)
• IBM PS2 (includes models 30, 70, 8556)
Keyboard Country Type
• **USA • German • Spanish
• Belgium • Italian • Swiss
• French • Japanese • United Kingdom
** Default setting. Refer the Default Settings chart on pages 35 - 39.
For information on how to change the default settings, refer to help files in
MetroSet2 or the MetroSelect Single-Line Configuration Guide.
