10
H OW TO S CAN
Three Modes of Operation
Auto Trigger, In-Stand
• Auto-triggers while in the stand
• Bar code is automatically decoded and transmitted
CodeGate, Out-of-Stand
• CodeGate activates when removed from the stand
• Bar code data is transmitted when the button is pressed
Manual Activation Mode*, Out-of-Stand
• Button activates laser
• Bar code data is scanned and transmitted while button is held down
How to Use CodeGate (MS9544) and the Manual Activation Mode
CodeGate ® Manual Activation Mode*
* This feature is not a default setting.
Refer to the MetroSelect Single-Line
Configuration Guide for instructions on
enabling the Manual Activation Mode.
Figure 9. Figure 10.
