Scanner parts – Metrologic Instruments MS9544 User Manual
Page 20
16
S
CANNER
P
ARTS
Item
No.
Description
1 White
LED,
see page 18
2
Yellow LED, available on the MS9544 only (see page 18).
3
CodeGate Button, available on the MS9544 only (see page 10).
4 Blue
LED,
see page 18
5
Output Window, Laser Aperture
6 Cable
Connection, see page 40 for connector pinouts
Figure 29.
