Chapter 4 - V.22bis Commands
Multi-Tech Systems, Inc. MT2456SMI-22 SocketModem Developer’s Guide
46
Code
Message
Meaning
16
CONNECT 19200
The modem has connected to the line, the DTE speed is 19200 bps and DTE
speed reporting is enabled.
22
CONNECT
75TX/1200RX
The modem has established a V.23 originate connection and line speed reporting
is enabled.
23
CONNECT
1200TX/75RX
The modem has established a V.23 answer connection and line speed reporting is
enabled.
24
DELAYED
For X4, sent when a call fails to connect and the number dialed is considered
'delayed' due to country blacklisting requirements.
32
BLACKLISTED
For X4, sent when a call fails to connect and the number dialed is considered
'blacklisted'.
59
CONNECT 16800
The modem has connected to the line, the DTE speed is 16800 bps and DTE
speed reporting is enabled.
61
CONNECT 21600
The modem has connected to the line, the DTE speed is 21600 bps and DTE
speed reporting is enabled.
62
CONNECT 24000
The modem has connected to the line, the DTE speed is 24000 bps and DTE
speed reporting is enabled.
63
CONNECT 26400
The modem has connected to the line, the DTE speed is 26400 bps and DTE
speed reporting is enabled.
64
CONNECT 28800
The modem has connected to the line, the DTE speed is 28800 bps and DTE
speed reporting is enabled.
83
LINE IN USE
The modem attempted to go off-hook when an extension was already occupying
the line.
84
CONNECT 33600
The modem has connected to the line, the DTE speed is 33600 bps and the DTE
speed reporting is enabled.
91
CONNECT 31200
The modem has connected to the line DTE speed is 31200 bps and the modem is
to report the DTE speed upon connecting.
Notes:
1. See Vn for result code selection, i.e., short form (result code) or verbose/extended (result message).
2. See Wn for extended connect message control.
3. See S95 for extended result code enabling options (which override some Wn commands).
4. See Xn for extended result code subset enabling options.
5. See \Vn for single line connect message enable options.
