26 49D0090 49D0090 27
�
�
��
��
�
�
�
�
�
�
�
�
�
ILLUSTRATED PARTS LIST
Failure to position the parts in
accordance with these diagrams or
failure to use only parts specifically
approved with this appliance may
result in property damage or personal
injury.
W
ARNING
ITEM DESCRIPTION QTY DHHNT DHHPT
1 Burner 1 49D0200 49D0200
2 Injector 1 49D0080 49D0081
3 ODS Pilot Valve Tube, 3/16 1 49D0050 49D0050
4 ODS Pilot Assembly 1 26D2529 14D0476
5 T-stat Control Valve 1 11V0701 11V0701
6 Pressure Valve Regulator 1 24D0305 24D0306
7 Piezo Wire 1 00K0632 00K0632
8 Burner Valve Tube, 5/16 1 49D0071K 49D0071K
9 Piezo Ignitor 1 14D0503 14D0503
LOG SET
10 Front Log 1 49D0053 49D0053
11 Rear Log 1 49D0052 49D0052
