User’s Guide
FX Routing
The Plug-in Configuration Window
Card Slot Column
Card B
Card C
Card D (no
card installed)
Card A
Plug-in
display toggle
Input Channel
Assignment Drop-
down Menu Button
Input Source As-
signment Column
Plug-in Assign-
ment Column
Close Window
Stereo/Mono
Mode Column
Stereo/Mono
Toggle Button
