OM-1582 Page 17
Ref. 143 259-G / Ref. SA-146 866-B / Ref. SA-148 666-E / Ref. SA-150 588-D
Tools Needed:
.
If wire feeder is equipped with a voltage sensing lead, set DIP switch S3
to the OFF position (up). If wire feeder is NOT equipped with a voltage
sensing lead, set DIP switch S3 to the ON position (down).
12
OFF
1
2
OFF
1 2
OFF
1 2
Or
Long Spot
Time
0-5 Seconds
Short Spot
Time
0-2.5 Seconds
X Means switch can be in either position.
. Means switch must be in this position.
Spot Time
Range Selection Option Interface
Standard Settings
1/4 in
4-10. Optional Equipment DIP Switch Settings
12
3
4
5
Or Or
High Speed
Motor
Meters/Minute
High Speed
Motor
Inches/Minute
Standard
Motor
Meters/Minute
Standard
Motor
Inches/Minute
Digital Meter Functions
12
Or
Arc Voltage Sensing Using
Voltage Sensing Lead
Voltage Sensing Function
Arc Voltage Sensing Using
Feedback From Welding
Power Source
12
DIP Switch S3
Set To OFF
DIP Switch S3
Set To ON
12
3
4
5
12
3
4
5
12
3
4
5
