PAGE 75 — DCA-25SSIU — PARTS AND OPERATION MANUAL (STD) — REV. #7 (04/18/12)
NO. PART NO. ITEM QTY. REMARKS
DCA-25SSIU --- MUFFLER ASSY.
MUFFLER ASSY.
1 0602300160 MUFFLER;MAM060249 ................. 1 ........... S/N7100001 TO 7105049
1 0602300390 MUFFLER ...................................... 1 ........... S/N7105050~
2 M133040004 MUFFLER SUPPORTER ............... 1 ........... S/N7100001 TO 7105049
3 011008020 HEX. HEAD BOLT .......................... 2 ........... REPLACES 0016908020;
S/N7100001 TO 7105049
3 011008020 HEX. HEAD BOLT .......................... 4 ........... REPLACES 0016908020; S/N7105050~
4 M1330400104 U BOLT 2 S/N7100001 TO 7105049
5 020108060 HEX. NUT ...................................... 4 ........... REPLACES 0037908000;
S/N7100001 TO 7105049
031108160 PLAIN WASHER ............................ 4 ........... REPLACES 0041208000;
S/N7100001 TO 7105049
6 M1333000703 EXHAUST PIPE 1
7 M1333000803 EXHAUST PIPE ............................. 1 ........... S/N7100001 TO 7105049
8 8943811610 GASKET ........................................ 1 ........... REPLACES 0602320102
9 M1333200004 GASKET ........................................ 1 ........... S/N 7100001 TO S/N7100865
M1333200014 GASKET ........................................ 1 ........... S/N7100866~
10 9098400850 HEX. NUT ...................................... 3 ........... REPLACES 0602323001
0040010000 LOCK WASHER 3
11 0016908035 HEX. HEAD BOLT 4
12 M1333000604 TAIL PIPE ...................................... 1 ........... S/N7100001 TO 7105049
13 0602325021 SEAL CLAMP ................................ 1 ........... S/N7100001 TO 7105049
14 M1330400204 COVER 2
15 011106015 HEX. HEAD BOLT .......................... 4 ........... REPLACES 0016906015
16 0602325020 SEAL CLAMP ................................ 1 ........... S/N7100001 TO 7105049
17 011008020 HEX. HEAD BOLT .......................... 4 ........... REPLACES 0016908020;S/N7105050~
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE
2-WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
