PAGE 61 — DCA-25SSIU — PARTS AND OPERATION MANUAL (STD) — REV. #7 (04/18/12)
NO. PART NO. ITEM QTY. REMARKS
DCA-25SSIU --- CONTROL BOX ASSY.
CONTROL BOX ASSY.
M1246700514 WIRE HARNESS, GENERATOR ................ 1 ......... UP TO S/N7106114
M1246700524 WIRE HARNESS, GENERATOR ................ 1 ......... S/N7106115~
1 M1213000202 CONTROL BOX ......................................... 1 ......... S/N7100001 TO 7102144
M1213000212 CONTROL BOX ......................................... 1 ......... S/N7102145 TO 7102314
M1213000222 CONTROL BOX ......................................... 1 ......... S/N7102315~
2 0601808810 CIRCUIT BREAKER .................................. 1 ......... FAF340601021 3P 60A;
UP TO S/N7106114
0601808820 CIRCUIT BREAKER .................................. 1 ......... S/N7106115~
3 021005080 MACHINE SCREW 4
4 0601842384 RESISTOR ................................................. 1 ......... GG20W 50 OHM
5 0027104010 MACHINE SCREW 2
6 0601821370 RECTIFIER ................................................ 3 ......... DE4503; REPLACES 0601823240
7 0021004040 MACHINE SCREW 1
0040004000 LOCK WASHER 1
031104080 PLAIN WASHER ........................................ 1 ......... REPLACES 0041204000
8 0601815925 TERMINAL BOARD ................................... 1 ......... 202HB SP
9 0027104020 MACHINE SCREW 2
10 0601823863 RELAY UNIT .............................................. 2 ......... MSA9013A
11 0021304015 MACHINE SCREW .................................... 4 ......... REPLACES 0027104015
12 0601820671 AUTOMATIC VOLTAGE REGULATOR ........ 1 ......... NTA5A2DB
13 0027105010 MACHINE SCREW .................................... 4 ......... S/N7100001 TO 7102574
0027105015 MACHINE SCREW .................................... 4 ......... S/N7102575~
14 0601806115 CURRENT TRANSFORMER ...................... 3 ......... 812943 50/5A
15 011808015 MACHINE SCREW .................................... 6 ......... REPLACES 0027106015
16 0601820845 OVER CURRENT RELAY .......................... 1 ......... LR2D1308
17 0601820846 OVER CURRENT RELAY .......................... 1 ......... LR7D1064
18 M1260600004 FITTING BRACKET ................................... 1 ......... S/N7100001 TO 7102314
19 0021304015 MACHINE SCREW .................................... 2 ......... S/N7100001 TO 7102314;
REPLACES 0027104015
0030004000 HEX. NUT .................................................. 2 ......... REPLACES 0207004000
20 0027104010 MACHINE SCREW 2
21 M1213500203 CONTROL BOX COVER 1
22 011106015 HEX. HEAD BOLT ...................................... 4 ......... REPLACES 0016906015
23 M1923100004 SELECTOR SWITCH ................................. 1 ......... VY40
24 M1213600104 SWITCH BRACKET ................................... 1 ......... S/N7100001 TO 7102144
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE
2-WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
