PAGE 73 — DCA-25SSIU — PARTS AND OPERATION MANUAL (STD) — REV. #7 (04/18/12)
NO. PART NO. ITEM QTY. REMARKS
DCA-25SSIU --- BATTERY ASSY.
BATTERY ASSY.
1 0602220185 BATTERY ....................................... 1 ........... 427MF
2 M9310500014 BATTERY SHEET 1
3 M9103000304 BATTERY BAND 1
4 M0602220920 BATTERY BOLT SET ..................... 2 ........... BHL10J;REPLACES M9103200004
5 0037808000 WING NUT ..................................... 2 ........... S/N7100001 TO S/N7100050
6 0040008000 LOCK WASHER ............................. 2 ........... S/N7100001 TO S/N7100050
0040006000 LOCK WASHER ............................. 2 ........... S/N7100051~
7 031108160 PLAIN WASHER ............................ 2 ........... S/N7100001 TO S/N7100050;
REPLACES 0041208000
8 0602220310 TERMINAL ASSY. ......................... 1 ........... NO.9P S/N7100001 TO S/N7100050
M134640004 BATTERY CABLE .......................... 1 ........... S/N7100051~
9 0602220311 TERMINAL ASSY. ......................... 1 ........... NO.9P S/N7100001 TO S/N7100050
M1346400104 BATTERY CABLE .......................... 1 ........... S/N7100051 TO S/N7101005
M2346400104 BATTERY CABLE .......................... 1 ........... S/N7101006~
10 M1346400004 TERMINAL COVER ....................... 1 ........... S/N7100001 TO S/N7100050;
REPLACES M9310000304
11 M1346400104 TERMINAL COVER ....................... 1 ........... S/N7100001 TO S/N7100050;
REPLACES M9310000204
12 0016910020 HEX. HEAD BOLT .......................... 1 ........... S/N7100051~
0040510000 TOOTHED WASHER ...................... 1 ........... S/N7100051~
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE
2-WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
