PAGE 69 — DCA-25SSIU — PARTS AND OPERATION MANUAL (STD) — REV. #7 (04/18/12)
ENGINE OPERATING PANEL ASSY.
DCA-25SSIU --- ENGINE OPERATING PANEL ASSY.
NO. PART NO. ITEM QTY. REMARKS
M1357200102A WIRE HARNESS, ENGINE 1
1 M1354300304 SLIDE LEVER 1
2 0601840190 KNOB .................................................... 1 ........... REPLACES M9320000004
3 020108060 HEX. NUT ............................................. 1 ........... REPLACES 0036003000
4 M1354200004 BRACKET ............................................. 1 ........... ASK CUST. SVC. FOR COLOR
5 020108060 HEX. NUT ............................................. 1 ........... REPLACES 0030008000
6 0605010503 SNAP PIN 1
7 M1354300204 GOVERNOR ROD 1
8 0602180106 BALL JOINT .......................................... 2 ........... LHSA8DE161
9 020108060 HEX. NUT ............................................. 2 ........... REPLACES 0030008000
10 0207006000 HEX. NUT 2
0041206000 PLAIN WASHER 2
11 1823100080 STARTER SWITCH ............................... 1 ........... REPLACES 0602100004
12 8944626110 PREHEAT LAMP ................................... 1 ........... REPLACES 0602102066
13 0602120095 TACHOMETER ...................................... 1 ........... 103680
14 0602120480 PICK UP, TACHOMETER ...................... 1 ........... 7154400
15 0602122093 OIL PRESSURE GAUGE ...................... 1 ........... 100174
16 0602122272 OIL PRESSURE UNIT .......................... 1 ........... 102225; S/N7100001 TO S/N7101239;
REPLACES 0602122207
17 M9200100004 ADAPTER 1
18 0602123090 WATER TEMPERATURE GAUGE ......... 1 ........... 100683
19 0602123201 WATER TEMPERATURE UNIT ............. 1 ........... 0209400
20 9095720140 PACKING .............................................. 1 ........... REPLACES 0602121109
21 0602121080 CHARGING AMMETER ....................... 1 ........... 100158
22 0602128090 FUEL GAUGE ....................................... 1 ........... 100176
23 0602103092 ALARM LAMP ....................................... 2 ........... PL05
0601810245 BULB ..................................................... 2 ........... E10 T10 DC18V
24 0601810141 PANEL LIGHT ....................................... 1 ........... ISUZU 9826800370
25 0601831330 SWITCH, PANEL LIGHT ....................... 1 ........... 900001
26 020108060 HEX. NUT ............................................. 1 ........... REPLACES 0207008000
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE
2-WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
