PRODUCT SPECIFICATIONS
3 – 1
SECTION 3
Product Specifications
Models and Capacities
Performance Specifications
MODEL 96147H8 94610H6 93073H4 92305H3 91536H2
Integrated Interface ATA-5 / Ultra DMA
Encoding Method E 2 PR4 RLL 16/17
Interleave 1:1
Servo System Embedded
Buffer Size / Type 2 MB SDRAM
Data Zones per Surface 16
Data Surfaces / Heads 8 6 4 3 2
Number of Disks 4 3 2 2 1
Areal Density 11.2 G b / i n 2 max
Track Density 27,300 tpi
Recording Density 340 - 412 kbpi
Flux Density 361 - 418 kfci
Bytes per Sector / Block 512
Sectors per Track 373 - 662
Sectors per Drive 120,060,864 90,045,648 60,030,432 45,023,328 30,015,216
MODEL 96147H8 94610H6 93073H4 92305H3 91536H2
Seek Times (typical read)
Track-to-Track 1.0 ms
Average (performance) < 9.0 ms
Average (silent mode) 15 ms
Full Stroke < 20.0 ms
Average Latency 5.55 ms
Rotational Speed (±0.1%) 5,400 RPM
Controller Overhead < 0.3 ms
Data Transfer Rate
To/From Interface
(UltraDMA - M4)
up to 100 MB/sec
To/From Interface
(PIO 4/Multi-word DMA M4)
up to 16.7 MB/sec
To/From Media up to 40.8 MB/sec
Start Time (0 to Drive Ready) 8.5 sec typical
Drive Configuration
MODEL 96147H8 94610H6 93073H4 92305H3 91536H2
Formatted Capacity (MB LBA Mode)
61,471 46,103 30,735 23,051 15,367
Maxtor defines one megabyte as 10 6 or one million bytes and one gigabyte as 10 9 or one billion bytes.
