1-3

Getting Started

C onnector s

Back Panel

- 1 PS/2 m ouse port
- 1 PS/2 keyboard port
- 1 DVI port (optional)
- 1 VGA port
- 1 parallel port supporting SPP/EPP/ECP mode
- 4 USB 2.0 ports
- 1 LAN jack (optional 10/100Mbps or Gigabit)
- 3 flexible audio jacks
- 1 1394 port (optional)

Onboard Pinheaders
- 3 USB 2.0 pinheaders
- 1 1394 pinheader (optional)
- 1 TV-out pinheader (optional)
- 1 Audio header (rear/center/side output)

Slots

- 1 PCI Express x16 slot
- 2 PCI slots
- 1 PCI Express x 1 slot

Form Factor

- Micro-ATX (24.5cm X 24.5 cm)

M ounting

- 8 mounting holes

For more information on compatible components, please visit
h t t p : / / w ww . m s i . c o m . t w / p r o g r a m / p r o d u c t s / m a i n b o a r d / m b d /
pro_mbd_cpu_support.php

http://www.msi.com.tw/program/products/mainboard/mbd/
pro_mbd_tr p_list.php
