MSI CX700D User Manual
Page 23
2-5
Hardware Setup
B. Playing MP3 - Media Player
Measured Voltage
Measured Amp.
Watts
Mainboard +3.3V
3.4
0.56
1.9040
Mainboard +5V
5.05
1.01
5.1005
Mainboard 5VSB
5.14
0.034
0.1748
Mainboard +12V
11.86
0.63
7.4718
Mainboard Power Consumption
14.6511
C. Running Network Application - Files Copy
Measured Voltage Measured Amp.
Watts
Mainboard +3.3V
3.4
1.33
4.5220
Mainboard +5V
5.05
1.04
5.2520
Mainboard 5VSB
5.14
0.039
0.2005
Mainboard +12V
11.86
0.6
7.1160
Mainboard Power Consumption
17.0905
D. Idle
Measured Voltage
Measured Amp.
Watts
Mainboard +3.3V
3.4
0.56
1.9040
Mainboard +5V
5.05
0.94
4.7470
Mainboard 5VSB
5.14
0.04
0.2056
Mainboard +12V
11.86
0.39
4.6254
Mainboard Power Consumption
11.4820
E. S3 Mode
Measured Voltage
Measured Amp.
Watts
Mainboard +3.3V
3.4
0
0.0000
Mainboard +5V
5.05
0
0.0000
Mainboard 5VSB
5.14
0.318
1.6345
Mainboard +12V
11.86
0
0.0000
Mainboard Power Consumption
1.6345
