THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Load charts
23
Grove TMS9000E
142.3’ + 33’ 142.3’ + 56’ 142.3’ + 72’ 142.3’ + 88’
Feet 5°-20° 20°-40° 5°-20° 20°-40° 5°-20° 20°-40° 5°-20° 20°-40°
35
40
45 13,800
50 13,800 12,200
55 13,800 12,200 8130
60 13,800 11,950 7790 7000
65 13,350 11,700 7490 7000
70 12,900 11,500 7210 6810 5520
75 12,450 11,350 6940 6000 6600 5470 5520
80 12,000 11,150 6690 5880 6410 5380 5520 4960
85 10,650 11,000 6460 5760 6230 5290 5460 4890
90 9490 9930 6260 5660 6050 5210 5400 4820
95 8450 8850 6060 5550 5880 5140 5330 4760
100 7520 7880 5880 5460 5730 5070 5270 4700
105 6690 7020 5700 5380 5580 5000 5210 4640
110 5950 6250 5550 5300 5450 4940 5140 4590
115 5280 5550 5400 5230 5320 4880 5080 4540
120 4680 4910 5260 5170 5180 4830 5020 4500
125 4130 4330 4730 5110 4610 4780 4580 4450
130 3620 3810 4210 4650 4090 4580 4050 4410
135 3160 3740 4140 3610 4060 3570 4060
140 2740 3300 3670 3170 3590 3120 3580
145 2350 2900 3230 2760 3140 2710 3140
150 1990 2520 2820 2380 2730 2330 2730
155 1660 2180 2440 2030 2350 1980 2340
160 1850 1700 1990 1650 1990
165 1550 1400 1660 1340 1650
170 1270 1110 1050 1340
175 1010 1040
Counterweight Outriggers
142 ft
Fixed lengths
26,000 lb 100%
24 ft 0 in
360 o
Pounds (thousands)
Boom Extension
33 ft - 56 ft
72 ft - 88 ft
Hydraulic luffing
swingaway/loads luffing
