THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
15
Grove TMS9000E
Load charts
Counterweight Outriggers
142 ft
Fixed lengths
48,500 lb 100%
24 ft 0 in
360 o
Pounds (thousands)
Boom Extension
33 ft - 56 ft
72 ft - 88 ft
Manual offsettable
swingaway
142.3' + 33' 142.3' + 56' 142.3' + 72' 142.3' + 88'
Feet 0° 20° 40° 0° 20° 40° 0° 20° 40° 0° 20° 40°
30 13,650
35 13,650 8470
40 13,650 8470
45 13,650 14,200 8470 6920
50 13,650 14,200 12,200 8470 6920 5520
55 13,650 14,200 12,200 8470 8700 6920 5520
60 13,650 14,200 12,200 8470 8670 6920 7440 5520
65 13,650 14,200 12,200 8470 8620 6920 7440 5520
70 13,650 14,100 12,200 8470 8380 6920 7440 5520 5680
75 13,650 13,500 12,200 8470 8160 6750 6920 7440 6370 5520 5610
80 12,950 12,900 12,200 8470 7940 6640 6920 7440 6370 5520 5550 5330
85 12,250 12,250 12,200 8470 7720 6530 6920 7430 6370 5520 5480 5330
90 11,600 11,600 11,850 8470 7530 6440 6920 7330 6370 5520 5420 5330
95 11,000 11,050 11,250 8470 7340 6350 6920 7240 6350 5520 5350 5330
100 10,450 10,500 10,700 8470 7170 6280 6920 7140 6270 5520 5290 5290
105 9860 9990 10,200 8470 7020 6210 6920 7040 6200 5440 5230 5240
110 9290 9510 9720 8340 6870 6140 6920 6840 6140 5350 5160 5200
115 8750 8980 9260 8100 6730 6090 6920 6630 6090 5270 5100 5150
120 8250 8470 8720 7770 6610 6050 6710 6430 6040 5180 5040 5110
125 7790 7990 8210 7420 6490 6010 6490 6240 6000 5100 4990 5050
130 7260 7520 7610 7090 6390 5990 6270 6050 5970 5010 4920 4990
135 6670 6890 6770 6290 5970 6020 5880 5950 4930 4850 4920
140 6130 6320 6460 6200 5970 5740 5710 5800 4840 4760 4860
145 5630 5780 6070 6130 5970 5470 5560 5660 4670 4600 4720
150 5160 5280 5600 6000 5970 5220 5410 5530 4520 4460 4580
155 4740 4820 5160 5520 5660 4980 5180 5410 4360 4320 4450
160 4340 4750 5070 4590 4950 5180 4220 4190 4320
165 3990 4370 4640 4200 4560 4720 4020 4060 4200
170 4020 4240 3840 4160 3760 3950 4090
175 3690 3860 3500 3790 3420 3770 3930
180 3380 3500 3190 3430 3100 3420 3550
185 3080 2890 3100 2800 3090
190 1830 2620 2780 2510 2770
195 2360 2480 2250 2470
200 2120 2000 2190
205 1910 1770 1920
210 1550 1660
215 1340
220 1160
