THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
12
Load charts
Counterweight Outriggers
36 ft - 142 ft
Fixed lengths
26,000 lb 100%
24 ft 0 in
360 o
Pounds (thousands)
Boom Extension
Feet 35.9' 49.2’ 63.0’ 75.5’ 89.1’ 102.7’ 116.2’ 129.5’ 142.3’
10 165,000 138,000 130,500 111,000 83,000
12 151,000 138,000 129,500 111,000 83,000
15 128,500 127,500 122,500 111,000 83,000 60,150
20 95,750 97,750 96,300 97,600 81,500 60,150 44,500 33,450
25 72,700 74,650 75,250 74,750 73,500 56,750 44,500 33,450 26,700
30 58,850 59,100 59,700 59,750 50,100 44,250 33,450 26,700
35 46,850 47,850 47,700 46,800 44,700 40,100 33,450 26,700
40 37,500 38,650 38,500 37,650 38,350 36,250 32,850 26,700
45 32,100 31,950 31,900 32,000 30,300 30,050 26,700
50 27,150 27,100 27,850 27,050 27,350 25,900 25,950
55 21,850 24,250 24,050 23,250 23,550 23,350 22,700
60 21,300 20,950 21,250 20,500 20,350 19,700
65 18,750 18,450 18,700 18,300 17,850 17,200
70 16,400 16,600 16,200 15,900 15,250
75 14,750 14,950 14,550 14,150 13,500
80 13,350 13,400 13,000 12,600 11,950
85 12,050 11,650 11,250 10,600
90 10,900 10,500 10,100 9470
95 7430 9480 9070 8450
100 8580 8170 7550
105 7770 7360 6740
110 6640 6020
115 6000 5380
120 5400 4790
125 4260
130 3770
135 3330
140
Counterweight Outriggers
36 ft - 142 ft
Fixed lengths
11,000 lb 100%
24 ft 0 in
360 o
Pounds (thousands)
Boom Extension
Feet 35.9' 49.2’ 63.0’ 75.5’ 89.1’ 102.7’ 116.2’ 129.5’ 142.3’
10 164,000 138,000 130,500 111,000 83,000
12 147,000 138,000 129,500 111,000 83,000
15 120,500 123,000 121,000 111,000 83,000 60,150
20 84,900 86,900 87,500 86,750 81,500 60,150 44,500 33,450
25 61,950 63,550 63,850 65,650 64,500 56,750 44,500 33,450 26,700
30 46,400 47,550 47,400 46,400 45,400 44,250 33,450 26,700
35 35,500 36,500 36,350 37,300 36,350 35,850 33,450 26,700
40 28,100 29,250 30,400 30,000 30,000 29,500 29,350 26,700
45 24,100 25,000 24,650 24,950 24,500 23,950 23,200
50 20,000 20,900 20,850 20,800 20,350 19,900 19,150
55 15,200 17,750 17,650 17,650 17,200 16,750 16,000
60 15,300 15,250 15,250 14,800 14,350 13,700
65 13,250 13,200 13,200 12,800 12,350 11,700
70 11,500 11,500 11,100 10,700 10,050
75 10,100 10,100 9730 9310 8660
80 8920 8930 8530 8110 7470
85 7890 7500 7080 6450
90 7000 6600 6190 5560
95 3750 5810 5400 4770
100 5120 4700 4080
105 4490 4090 3470
110 3530 2910
115 3040 2420
120 2580 1970
125 1560
130 1190
135
140
35.9’ 49.2’ 63.0’ 75.5’ 89.1’ 102.7’ 116.2’ 129.5’ 142.3’
Radius
10 164,000 138,000 130,500 111,000 83,000
12 147,000 138,000 129,500 111,000 83,000
15 120,500 123,000 121,000 111,000 83,000 60,150
20 84,900 86,900 87,500 86,750 81,500 60,150 44,500 33,450
25 61,950 63,550 63,850 65,650 64,500 56,750 44,500 33,450 26,700
30 46,400 47,550 47,400 46,400 45,400 44,250 33,450 26,700
35 35,500 36,500 36,350 37,300 36,350 35,850 33,450 26,700
40 28,100 29,250 30,400 30,000 30,000 29,500 29,350 26,700
45 24,100 25,000 24,650 24,950 24,500 23,950 23,200
50 20,000 20,900 20,850 20,800 20,350 19,900 19,150
55 15,200 17,750 17,650 17,650 17,200 16,750 16,000
60 15,300 15,250 15,250 14,800 14,350 13,700
65 13,250 13,200 13,200 12,800 12,350 11,700
70 11,500 11,500 11,100 10,700 10,050
75 10,100 10,100 9,730 9,310 8,660
80 8,920 8,930 8,530 8,110 7,470
85 7,890 7,500 7,080 6,450
90 7,000 6,600 6,190 5,560
95 3,750 5,810 5,400 4,770
100 5,120 4,700 4,080
105 4,490 4,090 3,470
110 3,530 2,910
115 3,040 2,420
120 2,580 1,970
125 1,560
130 1,190
135
140
