19
Grove TMS9000E
Load charts
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
142.3’ + 33’ 142.3’ + 56’ 142.3’ + 72’ 142.3’ + 88’
Feet 5°-20° 20°-40° 5°-20° 20°-40° 5°-20° 20°-40° 5°-20° 20°-40°
35
40
45 13,800
50 13,800 12,200
55 13,800 12,200 8130
60 13,800 11,950 7790 7000
65 13,350 11,700 7490 7000
70 12,900 11,500 7210 6810 5520
75 12,450 11,350 6940 6000 6600 5,470 5520
80 12,100 11,150 6690 5880 6410 5380 5520 4960
85 11,750 11,000 6460 5760 6230 5290 5460 4890
90 11,400 10,850 6260 5660 6050 5210 5400 4820
95 10,950 10,750 6060 5550 5880 5140 5330 4760
100 10,400 10,450 5880 5460 5730 5070 5270 4700
105 9870 9940 5700 5380 5580 5000 5210 4640
110 9290 9460 5550 5300 5450 4940 5140 4590
115 8750 8930 5400 5230 5320 4880 5080 4540
120 8250 8420 5260 5170 5200 4830 5020 4500
125 7780 7940 5130 5110 5080 4780 4970 4450
130 7280 7460 5010 5010 4970 4730 4890 4410
135 6680 4900 4900 4870 4690 4810 4380
140 6130 4780 4790 4780 4660 4720 4340
145 5620 4630 4690 4690 4620 4570 4310
150 5150 4480 4610 4540 4600 4420 4290
155 4710 4340 4520 4410 4520 4280 4260
160 4220 4290 4450 4150 4150
165 4090 4170 4380 4020 4020
170 3980 3870 3800 3910
175 3690 3520 3450 3710
180 3370 3200 3120 3350
185 2860 2790
190 2540 2460
195 2230 2160
200 1870
205 1590
210 1330
215
Counterweight Outriggers
142 ft
Fixed lengths
48,500 lb 100%
24 ft 0 in
360 o
Pounds (thousands)
Boom Extension
33 ft - 56 ft
72 ft - 88 ft
Hydraulic luffing
swingaway/loads luffing
