Overview
This chapter includes:
¾
LED Indicators
¾
Housing
• DIN Rail
• Wall Mount
LED Indicators
NPort Express’s top panel contains five LED indicators, as described in the
following table.
LED Name
LED Color
LED Function
red
Power is on.
PWR
off
Power is off, or power error condition exists.
orange
10 Mbps Ethernet connection.
Link
off
Ethernet cable is disconnected, or has a short.
green
NPort Server system is ready.
blinking
NPort is requesting an IP address from the
DHCP or BootP server. After receiving the IP,
the LED will stop blinking.
Note: The LED will also blink when you press
the reset button; see page 1-5 for details.
Ready
off
NPort Server has malfunctioned.
green
Serial data is being transmitted.
Serial Tx
off
Serial data is not being transmitted.
orange
Serial data is being received.
Serial Rx
off
Serial data is not being received.
