Hardware Preparation and Installation
2-8 MVME712-12/-13/A/AM/B Transition Modules and LCP2 Adapter Board UserÕs Manual
2
SCSI Termination
Because the MVME712x has no provision for SCSI connection, you must
ensure that the SCSI bus is terminated properly. The LCP2 adapter has sockets
(R1, R2, R3) for terminating the SCSI lines using three 8-pin SIP resistors. Refer
to the Installation Instructions for use of the terminators.
MVME712B Module Preparation
No preparation of the MVME712B is necessary. The location of the connectors
is illustrated in
Figure 2-5 .
