DCA-60SSI2 — PARTS AND OPERATION MANUAL— REV. #3 (09/15/01) — PAGE 87
NO. PART NO. ITEM QTY. REMARKS
ENCLOSURE ASSY.
DCA-60SSI2 --- ENCLOSURE ASSY.
1 7455111112 BASE 1
2 7455116004 FLOOR PANLE 1
3 0017108020 HEX. HEAD BOLT 12
4 7455116504 COVER 1
5 0017108020 HEX.HEAD BOLT 2
6 7455121012 FRONT FRAME ................................... 1 ............ UP TO S/N3656070
7455121022 FRONT FRAME ................................... 1 ............ S/N3656071~
7455109203 ACOUSTIC SHEET 1
7 0017108020 HEX. HEAD BOLT 6
8 0800251201 FILLER COVER 1
9 0027106016 MACHINE SCREW 2
10 7455125503 COVER, FRONT FRAME 1
7455109304 ACOUSTIC SHET 1
11 0017108020 HEX. HEAD BOLT 16
12 7455125304 COVER, FRONT FRAME 1
13 00171080220 HEX. HEAD BOLT 12
14 3385155104 COVER ................................................. 2 ............ UP TO S/N3656070
15 0017106020 HEX. HEAD BOLT ................................ 8 ............ UP TO S/N3656070
16 7455125104 COVER, FRONT FRAME 1
7455109404 ACOUSTIC SHEET 1
17 0017108020 HEX. HEAD BOLT 4
18 7455125704 COVER, FRONT FRAME 1
7455109504 ACOUSTIC SHEET 1
19 0017108020 HEX. HEAD BOLT 4
20 7455132013 CENTER FRAME ................................. 1 ............ UP TO S/N3656070
B4434300003 CENTER FRAME ................................. 1 ............ S/N3656071~
21 7455132213 CENTER FRAME ................................. 1 ............ UP TO S/N3656070
B4434300103 CENTER FRAME ................................. 1 ............ S/N3656071~
22 0010114040 HEX. HEAD BOLT ................................ 8 ............ UP TO S/N3656070
0030014000 HEX. NUT ............................................. 8 ............ UP TO S/N3656070
0040014000 LOCK WASHER ................................... 8 ............ UP TO S/N3656070
0041214000 PLAIN WASHER ................................... 16 .......... UP TO S/N3656070
22 0010124040 HEX. HEAD BOLT ................................ 8 ............ S/N3656071~
0030014000 HEX. NUT ............................................. 1 ............ S/N3656071~
0040014000 LOCK WASHER ................................... 8 ............S/N3656071~
0041214000 PLAIN WASHER ................................... 9 ............ S/N3656071~
23 0010112030 HEX. HEAD BOLT 10
0040012000 LOCK WASHER 10
0041212000 PLAIN WASHER 10
24 7455141122 REAR FRAME ...................................... 1 ............ UP TO S/N3656070
B4444000102 REAR FRAME ...................................... 1 ............ S/N3656071 TO 3700637
B4444000112 REAR FRAME ...................................... 1 ............ S/N3700638~
7455109603 ACOUSTIC SHEET 1
25 0017108020 HEX. HEAD BOLT 4
26 7455155003 COVER, REAR FRAME ....................... 1 ............ UP TO S/N3656070
B4444300203 COVER, REAR FRAME ....................... 1 ............ S/N3656071~
7455109713 ACOUSTIC SHEET 1
