DCA-60SSI2 — PARTS AND OPERATION MANUAL— REV. #3 (09/15/01) — PAGE 79
36 0602180108 BALL JOINT 1
37 020106050 HEX. NUT ........................................ 3 ......... REPLACES 0030006000
38 952404470 PLAIN WASHER .............................. 1 ......... REPLACES 0041206000
39 8111860103 SET BOARD, OUPUT TERMINAL 1
40 0801830204 OUTPUT TERMINAL 5
41 0801830704 HEX. HEAD BOLT 5
42 0039312000 HEX. NUT 10
43 0040012000 LOCK WASHER 15
44 0041412000 PLAIN WASHER 20
45 011208030 HEX. HEAD BOLT ............................ 5 ......... REPLACES 0017108030
46 8081865504 COVER, OUTPUT TERMINAL 1
47 0605010051 HINGE 2
48 0027103016 MACHINE SCREW 12
0207003000 HEX. NUT 6
49 0017106016 HEX. HEAD BOLT 2
50 0601811034 RECEPTACLE .................................. 2 ......... REPLACES 0601812565; CS6369 250V 50A;
51 0601811030 RECEPTACLE .................................. 2 ......... UP TO S/N3627236; 5-20R 125V0 20A
0601812598 RECEPTACLE .................................. 1 ......... S/N3627237~;GF53 OEM 125V 20A
52 0027103010 MACHINE SCREW 10
0207003000 HEX. NUT ...................................... 10 ......... REPLACES 0030003000
S8413 PLAIN WASHER ............................ 10 ......... REPLACES 0041203000
53 0601805306 CIRCUIT BREAKER ........................ 2 ......... UP TO S/N3627236; KM51 265V 40A
0601804887 CIRCUIT BREAKER ........................ 2 ......... S/N3627237~;REPLACES 0601805313
KM51 265V 20A
54 0601805840 CIRCUIT BREAKER ........................ 3 ......... KM52 265V 50A
55 8081816303 BRACKET, CIRCUIT BREAKER 1
0222100200 RUBBER SHEET 1
56 0017106016 HEX. HEAD BOLT 2
57 8085182004 RUBBER COVER 1
59 011206020 HEX. HEAD BOLT ............................ 6 ......... REPLACES 0017106020
60 8081865303 COVER, RECEPTACLE 1
61 12212045 HEX. HEAD BOLT ............................ 2 ......... REPLACES 0010012045
62 031112230 PLAIN WASHER .............................. 4 ......... REPLACES 0041612000
63 0805009804 RUBBER WASHER 2
64 0030012000 HEX. NUT 2
65 0601820015 RECTIFER ....................................... 4 ......... IS2762
66 0601802133 FUSE ............................................... 1 ......... 5A
67 0601851780 GROMMET ...................................... 2 ......... S/N3700638~
ENGINE OPERATING PANEL ASSY.
DCA-60SSI2 --- ENGINE OPERATING PANEL ASSY.
NO. PART NO. ITEM QTY. REMARKS
