Revision 0.07 34
S t r o b e : 5 O F F
Figure 3-59 Strobe Warning Signal
This display example shows that the strobe will not signal a warning condition. The signal definitions are:
– 1 Continuous
– 2 Intermittent, one second on at two second intervals
– 3 Double Tap, two beeps at 5 second intervals
– 4 Triple Tap, three short beeps at 15 second intervals
– 5 Off, strobe will not flash (default)
3.3.8.9 Trouble Signal Summary
The trouble signals are in response to one or more sensor faults, either as a defined current level, or because of
wiring problems
T r o u b l e S i g n a l s
B u z z
Figure 3-60 Trouble Signals
This display example shows that troubles are signaled by the internal Buzzer only.
3.3.8.10 Trouble Buzzer Signal
T r o u b l e S i g n a l s
B u z z : 4 T r i p l e
Figure 3-61 Buzzer Trouble Signal
This display example shows that the buzzer will signal a trouble condition with a triple tap signal. The signal
definitions are:
– 1 Continuous
– 2 Intermittent, one second on at two second intervals
– 3 Double Tap, two beeps at 5 second intervals
– 4 Triple Tap, three short beeps at 15 second intervals (default)
– 5 Off, buzzer will not sound
3.3.8.11 Trouble Horn Signal
T r o u b l e S i g n a l s
H o r n : 5 O F F
Figure 3-62 Horn Trouble Signal
This display example shows that the horn will not signal a trouble condition. The signal definitions are:
– 1 Continuous
– 2 Intermittent, one second on at two second intervals
– 3 Double Tap, two beeps at 5 second intervals
– 4 Triple Tap, three short beeps at 15 second intervals
– 5 Off, horn will not sound (default)
