Revision 0.07 28
3.3.6 Configure Strobe Submenu
The configuration parameters for the strobe are the same as those for relays. A strobe would not normally
require a minimum on time but this parameter allows a more versatile configuration.
3.3.6.1 Strobe Summary
S t r o b e 5 N o r m . O f f
D e l a y O n
Figure 3-37 Strobe Summary
This display example shows that the strobe has been configured to operate Normally Off, with a turn on delay
and no minimum on time.
Notice that the strobe number, 5, is underlined. This indicates that the digit keys can be used to jump to a
particular relay, horn or strobe. The relays are numbers 1, 2 and 3; the horn is number 4 and the strobe is 5.
3.3.6.2 Strobe Mode
S t r o b e N o r m . O f f
M o d e : 2
Figure 3-38 Strobe Mode
This display example shows that the strobe is configured to operate in the Normally Off mode. The valid modes
are:
– 2 Normally Off (default)
– 3 Normally On
3.3.6.3 Strobe Turn On Delay
S t r o b e D e l a y O n
( m m : s s ) 0 1 : 0 0
Figure 3-39 Strobe Turn On Delay
The default turn on delay is one minute and the maximum allowed value is fifteen minutes.
3.3.6.4 Strobe Minimum On Time
S t r o b e M i n . O n
( m m : s s ) 0 0 : 0 0
Figure 3-40 Strobe Minimum on time
The default minimum on time is zero and the maximum allowed value is fifteen minutes.
