Personalizing Your Phone
Page 14 Mitel ® 5312/5324 IP Phone User Guide– Issue 2, June 2010
Installing Designation Cards
If you program buttons on your 5324 IP Phone (see page 17 ), you can install a new paper
designation card with the revised button labels. (Paper designation cards are provided by your
system administrator.) You can usually slide the paper designation card out and replace it
without removing the lens (if necessary, see the following instructions to remove the lens for
either model).
If you have a 5324 IP Phone, you can remove the lens and install a fixed Mylar ® designation
card, which has labels for the programmable buttons under the display. Contact your system
administrator for the Mylar designation card.
To remove the lens and install the fixed Mylar designation card (5324 IP Phone):
1. Remove the screw that holds the option module on the back of the IP phone. Keep the
screw in a safe place—you must use it in step 6.
2. Lift the lower edge of the option module until you feel the inner tabs release, and then
gently lift the upper edge of the module. (To avoid damaging the module or the lens,
always lift the lower edge of the module first.)
3. Remove the lens by lifting the upper edge, and then sliding the lower edge down.
4. Place the fixed Mylar designation card on the face of the IP phone.
5. Slide the lens tabs into the underside of the IP phone.
6. Snap the lens tightly into place by applying pressure to both the middle and top of the
lens. Secure the option module using the screw from step 1..
Lens
Fixed Mylar
designation card
module
Option
