Accessories
Data Operation
1. Insert the round end of the iDEN Data Cable (NKN6521) into
the data cable receptacle located on the back of the charger, with
the Motorola logo facing upwards.
2. Connect the opposite end of the data cable to the PC.
Adding and removing a battery from the rear pocket
Figure 4. Adding and Removing a Battery from the Rear Pocket
1. Insert the battery with the Motorola label facing forward and the
(+ and -) symbols pointing downward.
2. To remove the battery, pull it forward, then up and out of the
Charger.
Desktop Charger Status
The Charger displays the battery’s charge status. The indicator will
show one of the following:
solid red =1-30%; solid yellow =31-60%; flashing green =61-90%;
solid green =91-100%.
N O T E : Charging times may vary when performing data
operations.
N O T E : If a battery is in the rear pocket...
and the i500plus with a battery is inserted into the
front pocket, the battery in the front pocket will
charge to full capacity before the battery in the
rear pocket is charged. The LED for the rear
pocket flashes yellow, indicating that its battery is
waiting to be charged.
To remove the battery from the rear pocket, hold
the base of the Charger and pull the battery
forward, then straight up.
1
1
2
INSERT REMOVE
