3 3
Chapter 3
Hardware: EIP3170, EIP3170I
This chapter provides hardware information for the MGate EIP3170 and EIP3170I.
The following topics are covered:
‰ Panel Layout
‰ LED Indicators
‰ Dimensions
‰ Jumpers
‰ Pin Assignments
¾ DB9 (Male)
¾ Terminal Block (RS-422)
¾ Power Input, Relay Output
‰ DIN-Rail, Wall Mounting
‰ Specifications
