9
INTRODUCTION
Characteristics
• Distortion typically <0.01%, or <0.02% up to full power at all
frequencies.
• Noise and hum <-94dBr at all volume settings.
• Acoustic output typically >111dB spl @ 1m.
• Acoustic noise <15dB spl @ 1m.
• Frequency response in room response within 3dB, 28Hz-20kHz.
Control
• 2 x Meridian Comms.
• 9-pin D connector for RS232 PC control, null modem, 9600 baud, 2N1, no
handshake.
Cabinet
• Thick MDF side panels sandwiched around steel plates for maximum
damping across all frequencies.
• Steel plates give magnetic shielding.
• Side panels available in black ash and rosewood.
• Separate mid-range enclosure built into main cabinet.
• DSP5500 and DSP5500C: 284mm x 1100mm x 450mm (11.2" x 43.3" x
17.7") (W x H x D).
• DSP5500HC: 1100mm x 285mm x 415mm (43.3" x 11.2" x 16.3")
(W x H x D).
• 65kg (143lb) each.
Power
• 100-125; 200-250V AC 50-60Hz.
• 20VA standby; 600VA max.
Meridian Audio reserves the right to amend product specifications at any
time.
