Meridian America Meridian DSP - Manual (Page 12)

7
INTRODUCTION
Control
• 2 x Meridian Comms.
• 9-pin D connector for RS232 PC control, null modem, 9600 baud, 2N1, no
handshake.
Cabinet
• Wood-veneered MDF with internal bracing and damping.
• Available in black ash, rosewood, and cherry.
• DSP5000: 210mm x 900mm x 297mm (8.3" x 35.4" x 11.7") (W x H x D).
• DSP5000C: 670mm x 195mm x 275mm (26.3" x 7.7" x 10.8") (W x H x D).
• 32kg (70lb) each.
Power
• 100-125; 200-250V AC 50-60Hz.
• 20VA standby; 300VA max.
Meridian Audio reserves the right to amend product specifications at any
time.
