Metra Electronics 99-9224 - Manual (Page 4)

99-9224
2
Remove (2) T-25 Torx head screws
from bottom of radio. Unplug and
remove the radio. (Figure E) 6
Depress the snaps on the top and
bottom of the pocket to remove it
from the radio bracket. (Figure F) 7
Remove (5) T-25 Torx head screws
securing the radio to the radio
bracket and slide the bracket off of
the radio. (See Figure G)
Note: Save the radio bracket for
use with radio housing. (Figure H) 8
DASH DISASSEMBLY
E
TOP SNAP
F
TORX
HEAD
G H
1999-2006 VOLVO S80
