21 115407
OWNER’S MANUAL
ILLUSTRATED
PARTS LIST
Solenoid and Control Board
Assemblies and Mounting
This list contains replaceable parts used in
your generator. When ordering parts, follow
the instructions listed under Replacement
Parts on page 23 of this manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 115404-02 Control Board Assembly (Includes
Circuit Board Locking Supports) 1
2 100324-03 Solenoid Assembly (Includes
Plunger, Nut, and Lock Washer) 1
3 102939-01 Solenoid Mounting Bracket 1
4 103811-01 Nylon Washer 1
5 103812-01 Retaining Ring 1
6 100755-02 Linkage Rod 1
7 22822000 Roll Pin 1
PARTS AVAILABLE NOT SHOWN
100320-01 Yellow Wire 1
100322-01 White Wire (with 2 Flags) 1
100322-02 White Wire (with 1 Flag and 1 Spade) 1
100366-01 Rocker Switch 1
