DVR1604RW Digital Video Recorder
Operational Manual © 2004 Mace Security Products. 33
DATE and TIME are used to modify the current system date and time; after the
modification reserve the change by selecting SAVETIME; in HDDFULL if
selecting OVERWRITE system covers the previous recording files;
RECORDLEN can set the length of each recording file(15 mins, 30 mins, 60
mins)Note: 15 minutes is suggested. COMMCT RL can activate the
communication control protocols. The existing comm control protocols are:
MODEM - Dial-up connection through modem.
AB- matrix control
DH Keyboard control
NONE upgrading system through serial port
Note: System time shall NOT be changed freely; otherwise it
would cause the malfunction of recording search.
Select the corresponding channel in CH . In WEEK the letter of each day
is chosen, when the letter displays are highlighted. TIME1 and TIME2
express the timed recording period of the current channel. TIME2 should
be after the ending time of TIME1. The setting range is 00:00-24:00
STATE ON means the time setting is on. OFF means the time setting is
OFF.
Note : 1: If you need to record all day long, set TIME1 as 00:00-24:00 &
state is on; set TIME2 as off. 2: When setting time in WEEK , several days
can be set at the same time.
When reviewing a certain channel’ s timing, only the current day will be
highlighted.
In CH option select the related channel. In MODE there are CBR
(audio/video) and VBR (audio/video). AV is audio and video synchronization,
Video is the mode without audio (when there is no audio input use this way to save
HDD space).When in CBR, Framerate is Real time, Bitrate is the related maximum
data flux. Use direction key to select the different bitrates. When in VBR,
Framerate 1f/s-25f/s are selectable. Video Loss on means that alarm will be on
when the video is lost, and also trigger the relay device.
Schedule
General
DATE 2003-07-13
FORMAT DD-MM -YY
TIME 08:30:30
FORMAT AM/PM SAVE TIME
HDDFULL OVERWRITE
REC -LENGTH 60 MIN
REMOTE ADDRESS 008
VIDEO MODE PAL
SHUT PASSWORD OFF
DEFAULT SAVE CANCEL
C H 0
WEEK TIME1 TIME2
SUN 00:00-24:00 ON 00:00 -24:00 OFF
MON00:00-24:00 ON 00:00-24:00 OFF
TUE 00:00-24:00 ON 00:00-24:00 OFF
WED 00:00-24:00 ON 00:00 -24:00 OFF
THU 00:00-24:00 ON 00:00-24:00 OFF
FRI 00:00-24:00 ON 00:00-24:00 OFF
SAT 00:00-24:00 ON 00:00-24:00 OFF
ALL 00:00-24:00 ON 00:00 -24:00 OFF
DEFAULT SAVE CANCEL
CH 0
NAME CHANNEL 01
QUALITY 0
FRAMERATE 25F/S
BITRATE VBR
VIDEO LOSS ALARM SHUT
ALARM
ALARM TIP NO TIP
COVER SET OFF
DEFAULT SAVE CANCEL
