SGW-250SS DC WELDER/AC GENERATOR — PARTS & OPERATION MANUAL — REV. #2 (08/08/01) — PAGE 57
SGW-250SS — ENCLOSURE ASSY.
ENCLOSURE ASSY.
NO PART NO PART NAME QTY. REMARKS
1 D2415000412 BASE 1
1-1 0226900130 EDGE COVER 1
2 D2415400014 BASE COVER 1
3 0016906016 HEX HEAD BOLT 4
4 D2305100004 ENGINE BASE 1
5 D2418500104 GENERATOR BASE 1
6 0016908020 HEX HEAD BOLT 6
7 D2418700103 COMMON BASE 1
7-1 D2498000004 LINING 1
8 3025419304 RUBBER SUSPENSION 2
9 D9312600104 RUBBER SUSPENSION 2
10 0207010000 HEX NUT 8
11 0010110045 HEX HEAD BOLT 2
0207010000 HEX NUT 2
12 0017110030 HEX HEAD BOLT 2
13 D2425000413 FRONT FRAME 1
13-1 D2492200114 LINING 1
14 0016908020 HEX HEAD BOLT 4
15 D2425200104 COVER FRONT FRAME 1
16 0016906016 HEX HEAD BOLT 6
17 D2485100213 PANEL 1
17-1 D2498200013 LINING 1
18 0016908020 HEX HEAD BOLT 2
19 D2445000402 REAR FRAME 1
20 0016908020 HEX HEAD BOLT 8
21 D2445300304 COVER REAR FRAME 1
22 0016906016 HEX HEAD BOLT 5
23 0016906016 HEX HEAD BOLT 1
0040506000 TEETHED WASHER 1
24 D2455400013 COVER 1
25 0016906016 HEX HEAD BOLT 4
26 D2465000303 ROOF PANEL 1
D2498500014 LINING 1
27 0016908020 HEX HEAD BOLT 19
28 D2332300014 COVER EXHAUST PIPE 1
29 0016906016 HEX HEAD BOLT 3
THE PART NUMBER SHOWN IS TEAL. ADD THE
FOLLOWING LETTERS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
MQW - WHITE
THE SERIAL NUMBER MAY BE REQUIRED.
