4
6. Carefully install the adapter by firmly press-
ing the card into the slot you have chosen,
applying even pressure until the adapter is
completely seated in the slot.
7. Fasten the retaining bracket with the screw
from the slot cover. Make sure the adapter
is properly aligned. Store the slot cover for
future use.
8. Replace the computer cover and reconnect
the power cord and all cables.
9. Attach the network cable to your adapter.
2.3 Card Configuration
The following configuration options are
available in the SETUP program:
• Auto Configuration
• Set Configuration
The Auto Configuration option allows
automatic configuration when a Maxtech NX-16
Series network adapter is installed in the PC. This
option will select valid I/O and IRQ addresses
when a conflict is detected with other adapter cards
installed in your PC.
The Set Configuration option allows
selection of operating parameters such as I/O Base
Address, IRQ selection, Transceiver, and Boot
ROM Address.
The default configuration parameters are:
I/O Base Address: 0300H
IRQ Line: 3
Transceiver: Twisted Pair (BNC on
NX-16B)
Boot ROM Address: Disable
