2.2 Hardware Installation
Installation of this adapter card requires
opening and manipulating your PC. Exercise cau-
tion at all times when working with AC powered
and static-sensitive equipment. Turn off and un-
plug your PC before installation. Discharge any
static electricity from your body by touching any
metal surface.
1. Turn off your computer and all peripherals.
2. Make a note of the power cord and other
cables connected to your computer and dis-
connect them.
3. Remove your computer’s cover (refer to
your computer’s owner manual).
4. Select any available expansion slot, and
then remove the slot cover (refer to Figure
1). A 16-bit expansion slot is recommended.
5. Touch the computer chassis before remov-
ing the adapter from its anti-static bag. This
will discharge any static electricity from
your body.
Figure 1
