10
must use solid copper conductors and UL codes
CM, CMR, and CMP are required. The computer
on the network is connected via a star topology (i.e.
each node is connected to a HUB, not to each
other). Maximum cable length is 300' (100 m).
10Base-2 networks uses a single conduc-
tor coaxial cable and BNC connectors. Use only
RG-58A/U or RG-58C/U coaxial cables. Each
network node is connected to the coaxial cable via
a T-connector (included). The minimum distance
between T-connectors is 1.6' (0.5m). The T-con-
nector must be plugged directly into the network
adapter (no cable is allowed between the T-con-
nector and the adapter). No more then 30 connec-
tions are allowed per segment and the maximum
segment length is 607' (185 m). The cable must be
terminated at each end by one 50-ohm terminator.
Section Six - Specifications
Network Standard: IEEE 802.3
EthernetInterface: ISA bus 8 or 16 bit, auto detect
Hardware Compability: NE2000
I/O address:
200, 220, 240, 260, 300, 320, 340, 360
IRQ line: 2 (9), 3, 4, 5, 10, 11, 12, 15
RAM buffer: 16 KB
Boot ROM address: C800, CC00, D000, D400, D800, DC00
Power: 0.33A @ 5V
Temperature: 0 to 55 degrees C (Operating); -20 to 80
degrees C (Non-operating)
Humidity: 10% to 90% (Non condensing)
Dimensions: 6.20" x 2.48"
Certification: FCC Part 15 Class A
Drivers: Novell NetWare 3.x, 4.0, NetWare LAN WorkPlace
TCP/IP, Novell LAN Analyzer for NetWare, Wollongong Path-
way Access, FTP PC/TCP, NCSA TCP/IP, LAN Manager V2.1,
Windows For Workgroups, IBM LAN Server 2.x, IBM LAN
Support V1.2, IBM OS/2 EE V2.0, DEC Pathworks V4.x, SUN
PC-NFS, Banyan VINES V5.5, IBM TCP/IP for DOS and OS/2
