Metrologic Instruments MS6200 User Manual
Page 4
iii
T
ABLE OF
C
ONTENTS
Keyboard Wedge Installation................................................................................ 5
Disconnecting the PowerLink Cable from the Scanner ........................................ 7
Scanner Parts....................................................................................................... 8
Audible Indicators................................................................................................. 9
Visual Indicators ................................................................................................. 10
Failure Modes..................................................................................................... 11
Scan Area........................................................................................................... 12
Labels................................................................................................................. 13
Maintenance....................................................................................................... 13
Troubleshooting Guide ....................................................................................... 14
RS-232 Demonstration Program ........................................................................ 18
Appendix A
Specifications ................................................................................................. 19
Appendix B
Default Settings .............................................................................................. 21
Appendix C
Scanner Pinout Connections .......................................................................... 25
Cable Connector Configurations .................................................................... 26
Appendix D
Warranty and Disclaimer ................................................................................ 28
Appendix E
Notices ........................................................................................................... 29
Appendix F
Patent Information .......................................................................................... 31
Index................................................................................................................... 32
