6. Technical Specifications
The following table lists the specifications of the MIL-SM801XX series.
Specifications
Standards Compliance IEEE 802.3 10Base-T Ethernet,
IEEE 802.3u 100Base-TX/FX Fast Ethernet
ANSI/IEEE 802.3 Auto-negotiation
Protocol CSMA/CD
Max Forwarding and
Max Filtering Rate 14,880 pps per Ethernet port
148,800 pps per Fast Ethernet port
LED Indicators Per Port: (10/100 UTP ): 100M, LK/ACT, FD/COL ( 3 LEDs )
Fiber Port: 100M, LK/ACT, FD/COL ( 3 LEDs )
Per Unit: Power
Copper Network
Cables 10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable
EIA/TIA-568 100-ohm ( 100m )
100Base-TX: 2-pair UTP/STP Cat. 5 cable
EIA/TIA-568 100-ohm ( 100m )
Fiber Link Max.
Distance ST/SC/MT-RJ/VF-45 Multi-mode:
Half-duplex: 412m, Full-duplex: 2Km
SC Single-mode:
Half-duplex: 412m, Full-duplex: 15~60Km
Dimensions 250mm x 132mm x 37mm (9.8” x 5.2” x 1.5”)
Weight 1080 ±20 g 2.4lbs
Storage Temp. -40ºC to 70ºC ( -40ºF to 158ºF)
Operational Temp. 0ºC to 45ºC ( 32ºF to 113ºF )
Operational Humidity 10% to 90% (Non-condensing)
External Power 100-240V AC, 50-60Hz
Power Consumption 17 Watts ( Max )
EMI FCC Class A, CE Mark
Safety UL, cUL
