Multiquip 60Hz Whisperwatt Generator DCA45USI2 - Manual (Page 53)

DCA45USI2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (01/12/11) — PAGE 53
GENERATOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 B3110001102 ROTOR ASSY. 1
1- 1 FIELD ASSY. 1
1- 2 0601820083 RECTIFIER 3
1- 3 0601822664 ZNR 1
1- 4 B3120100804 HOLDER, ZNR 1
1- 5 B3120100604 INSULATOR WASHER 3
1- 6 B3120100704 INSULATOR WASHER 5
1- 7 B3111100603 FAN 1
1- 8 B2163100004 COUPLING DISK ........................................3 ......... PURCHASE ITEM 1-8 AS A SET
1- 9 0010304016 HEX. HEAD BOLT 1
1-9A B2163700004 BALANCING WEIGHT 1
1-9B 0204004000 U-NUT 1
1-10 B3163200104 COUPLING WASHER 2
1-11 0342612030 HEX. SOCKET HEAD CAP SCREW 6
1-12 0046512000 WASHER, FLAT 6
1-13 0071906309 BEARING 1
2 0010310020 HEX. HEAD BOLT 8
3 0042510000 WASHER, LOCK 8
4 3130000903 STATOR ASSY. 1
4-1 0845041904 GROMMET 2
5 B3137000803 FIELD ASSY., EXCITER 1
6 0016008060 HEX. SOCKET HEAD CAP SCREW 4
7 0042508000 WASHER, LOCK 4
8 B3153000513 END BRACKET
9 0017108035 HEX. HEAD BOLT 6
10 B3153400504 PACKING 1
11 B3153400404 COVER, BEARING 1
12 0017106016 HEX. HEAD BOLT 3
13 0010310025 HEX. HEAD BOLT 12
14 0042510000 WASHER, LOCK 12
15 B5131300004 COVER, END BRACKET 1
16 0340406040 HEX. HEAD BOLT 1
17 0600815000 NUT 1
18 0041206000 WASHER, FLAT 1
19 B3131300804 COVER, END BRACKET 1
20 0029205012 MACHINE SCREW 4
21 0041205000 WASHER, FLAT 4
22 0605000455 RUBBER SUSPENSION 2
23 0030012000 HEX. NUT 2
23A 0040012000 WASHER, LOCK 2
23B 0041212000 WASHER, FLAT 2
