Tp24 TILe SaW • operaTIon and parTS manuaL — rev. #2 (04/12/12) — page 41
electric MOtOr assy.
no. parT no. parT name QTy. remarKS
1 TP100145 MOUNTING BLOCK 1
2 TP100146 MOTOR ASSy, M2 2HP 1
3 TP100147 BOLT, HEX M8 X 1.25 X 25L 4
4 TP100148 BOLT, COUNTERSUNK SOCKET, M8 X 1.25 X 30L 1
5 TP100082 NUT, NyLON M8 X 1.25 4
6 TP100149 ARMATURE AND WINDING ASSy 1
7 TP100150 MOTOR COVER 1
8 TP100151 CAP, CARBON BRUSH 2
9 TP100152 CARBON BRUSH, 17MM X 7 M (SET OF 2) 1
10 TP100153 WIND BAFFLE 1
11 TP100154 WASHER, SPRING M5 4
12 TP100155 WASHER, SPRING M4 4
13 TP100156 WASHER, NARROW M5 4
14 TP100157 WASHER, NARROW M4 4
15 TP100158 CROSS SCREW, M5 X .8 X 25L 4
16 TP100159 CROSS SCREW, M4 X .7 X CROSS SCRE
