Metrologic Instruments Stratos MS2x20 Series - Manual (Page 16)

11
S
CALE
C
ONFIGURATION
B
AR
C
ODES
Single or Dual Cable Scale Configuration Bar Codes
Quantitative Separator
The following bar codes can be used to configure a Single or
Dual Cable MS2
xx0.
If the MS2 xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2 xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Decimal Pt Separator
³ 9 9 6 0 9 4
Use a decimal point to separate the units
from fraction values on the remote display.
Comma Separator
³ 9 9 6 0 9 5
Use a comma to separate the units from
fraction values on the remote display.
