User’s Manual
80
Appendix F — Specifications
VIDEO
Signal Format NTSC or PAL (auto detect)
Video Input
Composite: 4 looping inputs, 1 Vp-p, auto-terminating,
75 Ohms
Monitor Outputs
Composite: One (BNC), 1 Vp-p, 75 Ohms
Analog RGB: One (VGA)
− NTSC: 30.8kHz (horizontal frequency) / 60Hz (vertical frequency)
− PAL: 30.8kHz (horizontal frequency) / 50Hz (vertical frequency)
Video Resolution 720x480 (NTSC), 720x576 (PAL)
Playback/Record Speed
(images per second) Standard: 120ips (NTSC), 100ips (PAL)
High: 60ips (NTSC), 50ips (PAL)
INPUTS/OUTPUTS
Alarm Input 4 TTL, NC/NO programmable, 4.3V threshold
Alarm Output
2 relay out, terminal block, NC & NO, 0.5A @ 125VAC,
1A @ 30VDC
Alarm Reset Input 1 TTL, terminal block
Internal Buzzer 80dB at 10cm
Network Connectivity 10/100 Base Ethernet, RS-232C for external modem
Audio Input 1 line in
Audio Output 1 line
CONNECTORS
Video Input Composite: 4 BNC
Video Loop Composite: 4 BNC
Monitor Output
Composite: 1 BNC
Analog RGB: 1 (VGA)
Audio In 1 RCA connector
Audio Out 1 RCA connector
Alarms Terminal block
Alarm Reset In Terminal block
Ethernet Port RJ-45
RS-232C Serial Port DB9 (P)
USB Port 1 on front panel (1.1)
IR Port 1 Remote Control
Specifications are subject to change without notice.
