Architectural and Engineering Specifications
Mitsubishi Digital Recorder (DX-TL1600U)
A. Features:
1. The digital multiplexer recorder will not be PC base.
2. The digital multiplexer recorder will be a Mitsubishi 16 channel color recorder.
3. The digital multiplexer recorder shall be of simplex operation and duplex via network connection.
4. The digital reorder will record in MJPEG format with five user selectable compression rates.
5. The digital multiplexer recorder will have two internal 61Giga Byte hard disk drives allowing for 7
days 24 hours of continues recording when recording is set 16 cameras and .93 fields per camera per
second.
6. The digital multiplexer recorder will allow connection of up to 2 additional external SCSI 100GB
drives increasing the recording period to 17 days of continues 24-hour recording.
7. The digital multiplexer recorder will feature time base correction thus eliminating the need for external
camera synchronization.
B. Operation:
1. The digital recorder will be operated via the front panel.
2. The digital multiplexer recorder shall have an easy to follow (VCR like) setup menu system.
3. The digital multiplexer recorder will use a JOG/SHUTTLE combination to navigate and set the
various menus and for playback features.
4. The digital multiplexer recorder menu will be in English.
C. Installation:
1. The digital multiplexer recorder shall have composite BNC Inputs and looping outputs for all sixteen
cameras.
2. The digital multiplexer recorder will auto detect cameras connected and provide a warning if no input
if a cameras is set to record but no signal is present.
3. The digital multiplexer recorder will have a SCSI port to allow connection via external supported
devices.
4. The digital multiplexer recorder will support the following listed SCSI devices.
Archive
a. OnStream Tape drives (ADR50)
b. HP SureStore DDS-2, 3
Copy
a. Fujitsu MO disk (640MB & 1.3GB)
b. Matsushita DVD RAM (LF/-D102JD)
c. IOMEGA Zip Drive (250MB)
Hard Disk Drives
a. Two, up to 100GB drives
5. The digital multiplexer recorder will auto detect all external devices connected via its SCSI port.
6. The digital multiplexer recorder will support firmware upgrades via Zip drive
7. The digital multiplexer recorder shall have the ability to synchronize other unit’s time clock.
