Pioneer Reference Series DEX-P9R - Manual (Page 38)

custom-fit speaker application chart
88
MODEL &
CAR BRAND INTRODUCTION DATE
E
C
G F
A
D
B
Car Model & LocationHigh Grade High Grade Separate 3-Way 2-Way Dual Speaker Speaker
Brand Introduction Separate Co-Axial Component Cone Interface Adaptor
Date Component Kits Plates
SKODA Fabia (9/99-) A TS-1785 (1) UD-M177VW
E TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
Felicia (10/94-) A TS-1376 TS-1356 TS-1346
C TS-H1703 (11) TS-H177 (11) TS-1756 (11) TS-1746 (11)
C TS-1785 (11)
Octavia 5-door (9/96-) A TS-1756 TS-1746
A TS-1785
E TS-1356 TS-1346
Octavia Break (9/96-) A TS-1756 TS-1746
A TS-1785
E TS-4638 TS-4628 TS-4621
TOYOTA Yaris (01/99-) A TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746 UD-M171
SUBARU Vivio (3/92-12/00) B TS-1056 TS-1046
SUZUKI Swift Cabrio (1/92-12/00) B TS-H107 TS-1056 TS-1046
Swift 3-door (12/91-12/00) B TS-H107 TS-1056 TS-1046
Swift 4-/5-door (12/91-12/00) B TS-H107 TS-1056 TS-1046
Vitara 3-door (2/91-12/96) B TS-H107 TS-1056 TS-1046
VOLVO S40 (9/95-) A TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
B TS-H107 TS-1056 TS-1046
C TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
V40 (9/95-) A TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
B TS-H107 TS-1056 TS-1046
H TS-H1303 TS-1356 TS-1346
440 (10/94-8/95) A TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
850/Wagon (10/91-12/96) A TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
B TS-876 TS-874
940/960 (10/90-12/96) A TS-1356 TS-1346
G TS-1356 TS-1346
VW Corrado (10/88-12/95) B TS-H107 TS-1056 TS-1046 AD-EU800S
E TS-4638 TS-4628 TS-4621 AD-EU800S
Golf II 3/5-door (8/83-10/91) B TS-H871 TS-876 TS-874
E TS-H467 TS-4638 TS-4628 TS-4621
Golf Variant CL (9/93-9/99) A TS-H1710 (1) TS-H177 TS-1776 TS-1756 TS-1746
A TS-H1703 TS-1785 AD-EU800S
B TS-H107 TS-1056 TS-1046 AD-EU800S
G TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746
G TS-1785
Golf III 3-door (11/91-9/97) A TS-H1710 (1)(7) TS-H177 (7) TS-1776 (7) TS-1756 (7) TS-1746 (7)
A TS-H1703 (7) TS-1785 (7)
B TS-H107 TS-1056 TS-1046
Golf III 5-door (11/91-9/97) A TS-H1710 (1)(7) TS-H177 (7) TS-1776 (7) TS-1756 (7) TS-1746 (7)
A TS-H1703 (7) TS-1785 (7)
B TS-H107 TS-1056 TS-1046
G TS-H1703 (2)(5) TS-H177 (2)(5) TS-1776 (2)(5) TS-1756 (2)(5) TS-1746(2) (5)
G TS-1785 (2)(5)
Vento (1/92-9/98) A TS-H1710 (1) TS-H177 TS-1776 TS-1756 TS-1746
A TS-H1703 TS-1785
B TS-H107 TS-1056 TS-1046
G TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746
G TS-1785
Golf IV 3-door (10/97-) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
A TS-1785 (1) UD-M174VW
Golf IV 5-door (10/97-) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
A TS-1785 (1) UD-M174VW
G TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
G TS-1785 (1) UD-M174VW
Bora (10/98-) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
A TS-1785 (1) UD-M174VW
G TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
G TS-1785 (1) UD-M174VW
Lupo (10/98-) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746 UD-M177VW
A TS-1785(1) UD-M177VW
Passat 4-door (4/88-8/93) B TS-H107 TS-1056 TS-1046
Passat Variant (4/88-8/93) B TS-H107 TS-1056 TS-1046
E TS-4638 TS-4628 TS-4621
Passat CL (9/93-8/96) B TS-H107 TS-1056 TS-1046 AD-EU800S
Passat Variant CL (9/93-8/96) B TS-H107 TS-1056 TS-1046 AD-EU800S
Passat (9/96-) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
A TS-1785 (1) UD-M174VW
G TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
G TS-1785 (1) UD-M174VW
Polo 3-door + Coupé (10/90-9/94) E TS-H467 TS-4638 TS-4628 TS-4621
Polo 3-door (10/94-9/99) A TS-H1703* (7) TS-H177* (7) TS-1776 (7) TS-1756 (7) TS-1746 (7) UD-M171*
A TS-H1710* (1)(7) TS-1785 (7) UD-M171*
B TS-H107 TS-1056 TS-1046
Polo Classic (1/96-9/99) A TS-H1703* (7) TS-H177* (7) TS-1776 (7) TS-1756 (7) TS-1746 (7) UD-M171*
A TS-H1710* (1)(7) TS-1785 (7) UD-M171*
B TS-H107 TS-1056 TS-1046
C TS-H467 TS-4638 TS-4628 TS-4621
Polo 5-door (10/99-8/01) A TS-H1703* TS-H177* TS-1776 TS-1756 TS-1746 UD-M171*
A TS-1785
Polo (9/01-) A TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
A TS-1785 UD-M174VW
G TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
G TS-1785 UD-M174VW
Sharan (9/95-) A TS-1776 TS-1756 TS-1746
A TS-1785 AD-EU800S
G TS-1776 TS-1756 TS-1746
G TS-1785 AD-EU800S
Beetle (10/98-) A TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
A TS-1785 UD-M174VW
F TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
F TS-1785 UD-M174VW
