custom-fit speaker application chart
84
Pioneer offers a wide range of Universal and Custom-Fit speakers to fit many cars. The chart
below lists many popular car models, and the Pioneer speakers which can fit them. With
Custom-Fit speakers, installation is easy and exact; they fit perfectly in the speaker holes —
no cutting or drilling necessary. If Universal speakers — see chart pages 89 – 91 — are
preferred, they can be mounted in the car’s speaker provisions with the use of an adapt0r kit
(see Accessories), or mounted in the back. (This list may not apply to all cars listed, because
not all cars in each country have all the required speaker provisions.)
MODEL &
CAR BRAND INTRODUCTION DATE
E
C
G F
A
D
B
Car Model & LocationHigh Grade High Grade Separate 3-Way 2-Way Dual Speaker Speaker
Brand Introduction Separate Co-Axial Component Cone Interface Adaptor
Date Component Kits Plates
ALFA ROMEO 145 (9/94-4/01) A TS-H1703* (1) TS-H177* TS-1776 TS-1756 TS-1746 UD-M171*
A TS-1785 (1)
F TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
146 (9/95-4/01) A TS-H1703* (1) TS-H177* TS-1776 TS-1756 TS-1746 UD-M171*
A TS-1785 (1)
G TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746
G TS-1785
155 (3/92-9/97) C TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746 UD-M171
C TS-1785 UD-M171
156 (9/97-) A TS-H1703* TS-H177* TS-1776 TS-1756 TS-1746 UD-M171*
A TS-1785
G TS-H1703* TS-H177* TS-1776 TS-1756 TS-1746 UD-M171*
G TS-1785
164 Super (3/92-9/98) A TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746
A TS-1785
166 (10/98-) A TS-1776 TS-1756 TS-1746
A TS-1785
C TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746
C TS-1785
G TS-1776 TS-1756 TS-1746
G TS-1785
AUDI 80 4-door (11/91-12/94) B TS-H107 TS-1056 TS-1046
90 Coupé (9/88-12/94) B TS-H107 TS-1056 TS-1046
V8 (10/88-4/94) B TS-H107 TS-1056 TS-1046
A4 4-door (01/01-) A TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
A TS-1785 UD-M174VW
G TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746 UD-M174VW
G TS-1785 UD-M174VW
A6 (3/97-) A TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746
A TS-1785
G TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746
G TS-1785
TT (10/98-) A TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746
A TS-1785
BMW 3-series 2-door (10/85-1/92) D TS-H1303 TS-1356 TS-1346
3 Touring (1/88-4/00) D TS-H1303 TS-1356 TS-1346
E TS-H107 TS-1056 TS-1046
3-series 4-door (12/90-2/98) D TS-H1303 TS-1356 TS-1346
3-series Coupé (1/92-1/99) D TS-H1303 TS-1356 TS-1346
3 Compact (3/94-10/00) D TS-H1303 TS-1356 TS-1346
5-series (1/88-6/95) C TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
D TS-H1303 TS-1356 TS-1346
5-series (7/95-) C TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
D TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
7-series (10/86-3/94) C TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
D TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
MINI (10/00-) A TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746 UD-M177VW
CITROËN AX exc. HIT 3-door (8/91-9/96) F TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
AX exc. HIT 5-door (8/91-9/96) A TS-1376 TS-1356 TS-1346
AX HIT 3-door (8/91-9/96) F TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
AX HIT 5-door (8/91-9/96) A TS-1376 TS-1356 TS-1346
BX (8/86-2/93) A TS-1356 TS-1346
Saxo 3-door (10/96-9/01) A TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
Saxo 5-door (10/96-9/01) A TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
G TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
Xantia (3/92-12/00) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746
A TS-1785 (1)
G TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
XM 4-door (7/89-12/00) A TS-H1703 TS-H177 TS-1756 TS-1746
A TS-1785
E TS-1376 TS-1356 TS-1346
XM Break (1/92-12/00) A TS-H1703 TS-H177 TS-1756 TS-1746
A TS-1785
E TS-1356 TS-1346
C3 (09/01-) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746
A TS-1785 (1)
C5 (01/01-) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746
A TS-1785 (1)
G TS-H1703 TS-H177 TS-1776 TS-1756 TS-1746
G TS-1785
ZX Reflex/Avantage (4/91-9/97) A TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
ZX Aura/Volcano (4/91-9/97) A TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
G TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
ZX 3-door (10/92-9/97) A TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
F TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
ZX Break (4/91-2/98) A TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
G TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
Xsara 5-door (10/97-) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746
A TS-1785 (1)
G TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
Berlingo (10/96-9/02) B TS-H107 TS-1056 TS-1046
Berlingo (10/02-) A TS-1756 TS-1746
A TS-1785 (1)
Evasion (3/94-9/02) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746
A TS-1785 (1)
F TS-H1703* TS-H177* TS-1776 TS-1756 TS-1746 UD-M171*
F TS-1785 UD-M171
C8 (10/02-) A TS-1756 TS-1746
A TS-1785 (1)
Xsara Break (3/98-) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746
A TS-1785 (1)
G TS-H1303 TS-H137 TS-1376 TS-1356 TS-1346
Xsara Coupé (10/98-) A TS-H1703 (1) TS-H177 TS-1776 TS-1756 TS-1746
