Please see pages 84 – 88 for custom-fit speaker application chart.
83
Alfa Romeo, Audi, BMW, Citroën, Fiat, Mercedes-Benz, Peugeot,
Renault, Rover, Saab, Seat, Subaru, Suzuki, Volkswagen, Volvo
• Round/square compatible frame • Round/square compatible frame
10 CM 2-WAY SPEAKERS TS-1056
100 W
Max.
i
43
Ш102
Ш117
Alfa Romeo, Audi, BMW, Citroën, Fiat, Mercedes-Benz, Peugeot,
Renault, Rover, Saab, Seat, Subaru, Suzuki, Volkswagen, Volvo
10 CM DUAL-CONE SPEAKERS TS-1046
100 W
Max.
i
43
Ш102
Ш117
Fiat*, Saab, Seat, Volkswagen
* Fiat Punto with adapter UD-M870.
8.7 CM 2-WAY SPEAKERS TS-876
40 W
Max.
89 13 40
87 70
Fiat Punto
8.7 CM 2-WAY SPEAKERS TS-875
50 W
Max.
i
Fiat*, Saab, Seat, Volkswagen
* Fiat Punto with adapter UD-M870.
8.7 CM DUAL-CONE SPEAKERS TS-874
40 W
Max.
89 13 40
87 70
Daewoo, Fiat, Lancia, Nissan, Seat, Volkswagen
4” x 6” 3-WAY SPEAKERS TS-4638
70 W
Max.
157
85 x 143
99
Daewoo, Fiat, Lancia, Nissan, Seat, Volkswagen
4” x 6” 2-WAY SPEAKERS TS-4628
50 W
Max.
85 x 143
95
153
Daewoo, Fiat, Lancia, Nissan, Seat, Volkswagen
4” x 6” DUAL-CONE SPEAKERS TS-4621
60 W
Max.
123
43
73 95
153
85 x 143
17 cm 17 cm 17 cm 13 cm 13 cm 13 cm
42 mm 42 mm
42 mm 36 mm
10 mm 10 mm
• • • • • •
• • •
• • •
30 – 26,000 Hz 30 – 22,000 Hz 30 – 22,000 Hz 40 – 26,000 Hz 40 – 22,000 Hz 40 – 22,000 Hz
92 dB 92 dB 92 dB 91 dB 91 dB 90 dB
35 W 35 W 35 W 25 W 25 W 25 W
TS-1776 TS-1756 TS-1746 TS-1376 TS-1356 TS-1346
IMPP Cone woofer (Ø)
Cone midrange with Neodymium magnet (Ø)
Cone tweeter (Ø)
Tweeter (Ø)
Shallow basket design
Easy Connector
DIN/Peugeot type terminal
Frequency Response
Sensitivity (1 W/1 m)
Nominal input power
10 cm 10 cm 8.7 cm
8.7 cm 8.7 cm 4” x 6” (95 x 153 mm) 4” x 6” (95 x 153 mm) 4” x 6” (95 x 153 mm)
42 mm
30 mm 38 mm 30 mm 42 mm
11 mm
• •
• •
45 – 22,000 Hz 45 – 22,000 Hz 90 – 20,000 Hz 75 – 30,000 Hz 90 – 20,000 Hz 45 – 28,000 Hz 45 – 25,000 Hz 50 – 20,000 Hz
90 dB 90 dB 90 dB 89 dB 90 dB 90 dB 90 dB 90 dB
20 W 20 W 10 W 10 W 10 W 15 W 10 W 10 W
TS-1056 TS-1046 TS-876 TS-875 TS-874 TS-4638 TS-4628 TS-4621
IMPP Cone woofer (Ø)
Cone woofer (Ø)
Cone midrange (Ø)
Cone tweeter (Ø)
Tweeter (Ø)
Shallow basket design
DIN/VAG & Renault type terminal
Frequency Response
Sensitivity (1 W/1 m)
Nominal input power
