Pioneer Reference Series DEX-P9R - Manual (Page 27)

Please see pages 89 – 91 for universal speaker application chart.
77
TS-A6920
360 W
Max.
i
86
153
x 225
265
185
6” x 9” 4-WAY SPEAKERS
TS-A6900
240 W
Max.
i
82
153
x 225
264
185
6” x 9” 2-WAY SPEAKERS
TS-A6910
330 W
Max.
i
84.3
153 x 225
265
185
6” x 9” 3-WAY SPEAKERS
TS-A1310
150 W
Max.
i
52
Ш121
Ш157
13 CM 3-WAY SPEAKERS TS-A1710
200 W
Max.
i
66
Ш147
Ш179
17 CM 3-WAY SPEAKERS
NEW
NEW
17 cm 13 cm 25 cm 20 cm 6” x 9” 6” x 9” 17 cm 13 cm
(163 x 237 mm) (163 x 237 mm)
6” x 9”
(163 x 237 mm)
66 mm
66 mm 66 mm 66 mm 42 mm 42 mm
28 mm 28 mm
18 mm 18 mm 18 mm 18 mm 66 mm 10 mm 10 mm
• •
28 — 30,000 Hz 40 — 30,000 Hz 25 — 30,000 Hz 25 — 30,000 Hz 25 — 32,000 Hz 25 — 30,000 Hz 28 — 26,000 Hz 28 — 30,000 Hz 40 — 30,000 Hz
92 dB 91 dB 93 dB 93 dB 93 dB 93 dB 93 dB 92 dB 91 dB
60 W 40 W 100 W 90 W 80 W 80 W 40 W 50 W 35 W
Crystalline IMPP Cone woofer
with Butyl rubber edge (Ø)
Crystalline IMPP Cone woofer (Ø)
PPC (Pearl PolyCarbon) balanced dome midrange (Ø)
Cone Midrange (Ø)
PEI balanced dome tweeter
with Neodymium magnet (Ø)
Tweeter (Ø)
In-line crossover network
Frequency Response
Sensitivity (1 W/1 m)
Nominal input power
TS-A171C TS-A131C TS-A2510 TS-A2010 TS-A6920 TS-A6910 TS-A6900 TS-A1710 TS-A1310
